Mitsubishi Galant IX facelift (2006-2009) left right off Wiring diagram
This page shows the only wiring diagram for the component.left right off, which is found in the car Mitsubishi Galant IX facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right off (1 of 1)
BLK WIRE
BLU WIRE
C-211
DEFOGGER SYSTEM
DOWN
FUSE 14
GRN WIRE
GRN/RED WIRE
HOT IN ACC OR ON
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT
LEFT OFF
LEFT REMOTE CONTROLLED MIRROR (AT MIRROR)
LEFT RIGHT OFF
LT GRN WIRE
MIRROR HEATER
NCA WIRE
ORG/ WIRE
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT
RIGHT REMOTE CONTROLLED MIRROR (AT MIRROR) MIRROR HEATER
YEL WIRE
Go to component -> Power mirror circuit -> LEFT RIGHT OFF
