Mitsubishi Galant IX facelift (2006-2009) generator malfunction light ind Wiring diagrams

This page contains all the electrical diagrams for the component. generator malfunction light ind, in which he is found in the car Mitsubishi Galant IX facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram generator malfunction light ind (1 of 3)

Wiring diagram generator malfunction light ind for Mitsubishi Galant IX facelift (2006-2009) (1 of 3)

Get access

BATTERY BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE COMBI- NATION METER FUSE 13 FUSE 23 FUSIBLE LINK 4 GENERATOR GENERATOR MALFUNCTION LIGHT IND IGNITION SWITCH JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LOCK POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) RED/BLK WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) RUN WIRE STARTING CIRCUIT WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL/BLK WIRE

Go to component -> Charging circuit -> GENERATOR MALFUNCTION LIGHT IND

Wiring diagram generator malfunction light ind (2 of 3)

Wiring diagram generator malfunction light ind for Mitsubishi Galant IX facelift (2006-2009) (2 of 3)

Get access

2.4L A/T TEMP IND ANTI-LOCK BRAKE IND ANTI-THEFT SYSTEM BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRAKE IND COMBINATION METER CRUISE IND DOOR IND FOG IND FUEL GAUGE FUEL IND FUSE 20 FUSE 22 FUSE 23 GENERATOR MALFUNCTION LIGHT IND GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT W/ TAILLIGHT RELAY ENERGIZED ILLUM IMMOBILIZER IND JOINT CONNECTOR 1 (UPPER LEFT END OF DASH) JOINT CONNECTOR 2 LCD ODO/TRIP LEFT TURN IND MAIN CLOCK MALFUNCTION IND LAMP ODO/TRIP SWITCH OIL IND PARKING BRAKE SWITCH PRESSURE SWITCH RED WIRE RED/WHT WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) RHEOSTAT CIRCUIT RIGHT TURN IND SEAT BELT IND SOUND SYSTEMS SPEEDOMETER SRS IND STARTING/CHARGING SYSTEM SUB CLOCK TACHOMETER TCL IND TCL OFF IND TEMP GAUGE TIRE AIR IND UPPER BEAM IND WARNING SYSTEM WHT/BLK WIRE YEL WIRE YEL/GRN WIRE

Go to component -> Instrument cluster circuit, with multi-communication system (1 of 2) -> GENERATOR MALFUNCTION LIGHT IND
