Mitsubishi Galant IX facelift 2 (2008-2012) on- +res off Wiring diagram
This page shows the only wiring diagram for the component.on- +res off, which is found in the car Mitsubishi Galant IX facelift 2 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on- +res off (1 of 1)
3 C-303
31 C-29 C-306
5 15 C-31
5 A-13
6 14 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
A-13
ABS/TCL-ECU (RIGHT REAR CORNER OF ENGINE COMPT)
AUTO-CRUISE CONTROL SWITCH
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
C-211
C-214
C-29
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM HALL IC (SUB)
FUSE 22
FUSE 23 FUSE 22 LEFT SIDE OF DASH)
FUSE 9
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HALL IC (MAIN)
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 11
HOT IN ON OR START
IGNITION SWITCH
JOINT CONNECTOR 1 (UPPER LEFT END OF DASH)
JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK (BEHIND
LOCK ON
LT BLU WIRE
LT GRN/BLK WIRE
MAIN
MFI RELAY (ON ENGINE COMPT RELAY BOX)
OFF
ON CAN
ON ON/OFF OFF
ON SET OFF
ON- +RES OFF
ORG/BLU WIRE
PNK/BLK WIRE
PNK/GRN WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RHEOSTAT CIRCUIT
STARTING/ CHARGING SYSTEM
STOPLIGHT SWITCH (ATTACHED TO PEDAL SUPPORT MEMBER)
SUB +
THROTTLE ACTUATOR CONTROL MOTOR
THROTTLE ACTUATOR CONTROL MOTOR RELAY (ON ENGINE COMPT RELAY BOX)
THROTTLE BODY ASSEMBLY
TRANSMISSION RANGE SWITCH
TRANSMISSIONS SYSTEM
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> ON- +RES OFF
