Mitsubishi Galant IX facelift 2 (2008-2012) left occupant classification sensor (under left side of front passenger's seat) wiring diagram
This page shows the only wiring diagram for the component.left occupant classification sensor (under left side of front passenger's seat), which is found in the car Mitsubishi Galant IX facelift 2 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left occupant classification sensor (under left side of front passenger's seat) wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
C-11
C-29
C-307
CLOCK- SPRING
GRN WIRE
GRY WIRE
LEFT OCCUPANT CLASSIFICATION SENSOR (UNDER LEFT SIDE OF FRONT PASSENGER'S SEAT)
LT BLU WIRE
NCA WIRE
OCCUPANT CLASSIFICATION ECU (UNDER FRONT PASSENGER'S SEAT)
OFF
OFF OFF ON ON
OFF ON
ON OFF
ON OFF OFF ON
ON OFF OFF ON ON
PNK WIRE
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LEFT OCCUPANT CLASSIFICATION SENSOR (UNDER LEFT SIDE OF FRONT PASSENGER'S SEAT)
