Mitsubishi Galant IX facelift 2 (2008-2012) c-111 radio, cd player, cd wiring diagram
This page shows the only wiring diagram for the component.c-111 radio, cd player, cd, which is found in the car Mitsubishi Galant IX facelift 2 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
c-111 radio, cd player, cd wiring diagram (1 of 1)
ASC OFF SWITCH
BLK WIRE
BLK/YEL WIRE
C-02 (BEHIND INSTRUMENT CLUSTER)
C-111
C-111 RADIO, CD PLAYER, CD
C-16
C-16 A/C-ECU (BEHIND LOWER CENTER OF DASH)
C-211
C-214 JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
C-218
C-29
C-35
COLUMN ECU
COLUMN SWITCH
COMBINATION METER
DIMMER SWITCH
FOG LIGHT SWITCH
FRONT ECU
FUSE 20
FUSE 22
FUSE 23
GLOVE BOX LIGHT
GRN WIRE
GRN/WHT WIRE
HAZARD WARNING LIGHT SWITCH
HEAD
HEATED SEAT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM
JOINT CONNECTOR
JOINT CONNECTOR C-01 (UPPER LEFT END OF DASH)
JUNCTION BLOCK
KEY REMINDER SWITCH
LIGHTING SWITCH
MICROPHONE SWITCH
MULTI CENTER DISPLAY UNIT
NCA WIRE
PASSENGER'S SIDE AIR BAG OFF INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
RED WIRE
RELAY BOX (LEFT SIDE OF ENGINE COMPT)
RHEOSTAT
RHEOSTAT CIRCUIT
SHIFT SWITCH ASSEMBLY
TAIL
TAILLIGHT RELAY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> C-111 RADIO, CD PLAYER, CD
