Mitsubishi Galant IX facelift 2 (2008-2012) 23 28 29 c-117 41 29 40 c-134 Wiring diagram
This page shows the only wiring diagram for the component.23 28 29 c-117 41 29 40 c-134, which is found in the car Mitsubishi Galant IX facelift 2 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 23 28 29 c-117 41 29 40 c-134 (1 of 1)
23 28 29 C-117 41 29 40 C-134
3 C-35
5 6 2 C-35
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN/BLK WIRE
BRN/WHT WIRE
C-29
FUSE 22
FUSE 23
GRN/WHT WIRE
HANDS FREE MODULE (RIGHT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR ACC
ILL
INTER PHONE MICROPHONE (UNDER PASSENGER'S SEAT)
LT GRN WIRE
MICROPHONE SWITCH
OFF HOOK
ON HOOK
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
RELAY BOX (LEFT SIDE OF ENGINE COMPT)
VIO WIRE
W/ AUDIO AMPLIFIER
W/O AUDIO AMPLIFIER
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Hands free module circuit -> 23 28 29 C-117 41 29 40 C-134
