Manual a/c circuit, low option for Mitsubishi Galant IX (2003-2006)

A/C PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT) A/C- ECU AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER AIR THERMO SENSOR (ABOVE ACCELERATOR PEDAL) AMBIENT TEMPERATURE SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER) BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CONDENSER FAN RELAY (ON RELAY BOX) DEFOGGER SYSTEM ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPT) FAN CONTROL RELAY (ON ENGINE COMPT RELAY BOX) FUSE 20 FUSE 22 FUSE 23 FUSIBLE LINK 2 FUSIBLE LINK 26 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON HOT W/ TAILLIGHT RELAY ENERGIZED J/C 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 1 (UNDER LEFT END OF DASH) JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 2 (UNDER LEFT END OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MODE SELECTION DAMPER CONTROL MOTOR, POTENTIOMETER NCA WIRE OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL MOTOR RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT) RADIATOR FAN RELAY (ON RELAY BOX) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

5 10 B-19 81 69 B-21 93 B-22 A/C COMPRESSOR ASSEMBLY A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (ON ENGINE COMPT RELAY BOX) A/C REFRIGERANT TEMPERATURE SWITCH BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RELAY BLOWER SWITCH BLU WIRE BLU/ORG WIRE BLU/RED WIRE C-211 C-215 DATA LINK 6 14 CONNECTOR (UNDER LEFT SIDE OF DASH) ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE FUSE FUSE 20 FUSE 6 GRN WIRE HOT AT ALL TIMES HOT IN ON JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) NCA WIRE OFF OFF LO ML MH POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) RED WIRE RESISTOR WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
