Mitsubishi Galant IX (2003-2006) sport mode Wiring diagrams

AUTO MODE B-22 BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE CRANKSHAFT POSITION SENSOR (FRONT OF ENGINE) ENGINE CONTROLS SYSTEM GRN/RED WIRE GRN/YEL WIRE POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE SELECT SWITCH SHIFT SWITCH (UP) SHIFT SWITCH ASSEMBLY SHIFT SWITCH (DOWN) SPORT MODE WHT/BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

AUTO MODE BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE EXHAUST GAS RECIRCULATION VALVE (LEFT REAR OF ENGINE COMPT) FUEL LEVEL SENSOR (MAIN) FUEL TANK TEMPERATURE SENSOR GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INJECTOR 5 INJECTOR 6) INSTRUMENT CLUSTER SYSTEM PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SELECT SWITCH SHIFT SWITCH (UP) SHIFT SWITCH ASSEMBLY SHIFT SWITCH (DOWN) SPORT MODE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
