Mitsubishi Galant IX (2003-2006) multi- purpose fuse 23 Wiring diagram
This page shows the only wiring diagram for the component.multi- purpose fuse 23, which is found in the car Mitsubishi Galant IX (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi- purpose fuse 23 (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/RED WIRE
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DEDICATED FUSE 22
DOOR IND
DRIVER'S SEAT BELT BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
GRN/BLK WIRE
GRN/ORG WIRE
HEAD/TAIL LAMP ON
HOT AT ALL TIMES
HOT IN RUN OR START
JOINT CONNECTOR 1 (UPPER LEFT END OF DASH)
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LEFT FRONT DOOR SWITCH
LT GRN WIRE
MULTI- PURPOSE FUSE 23
NCA WIRE
ORG/BLK WIRE
RED WIRE
RED/WHT WIRE
SEAT BELT IND
WHT WIRE
Go to component -> Warning systems circuit -> MULTI- PURPOSE FUSE 23
