Mitsubishi Galant IX (2003-2006) column ecu turn signal light Wiring diagram
This page shows the only wiring diagram for the component.column ecu turn signal light, which is found in the car Mitsubishi Galant IX (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram column ecu turn signal light (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
COLUMN ECU TURN SIGNAL LIGHT
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ETACS-ECU
FUSE 20
FUSE 23
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING LIGHT SWITCH
HEAD
HOT IN ON
HOT IN ON OR START
JOINT CONNECTOR 2
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT
LEFT FRONT DOOR SWITCH RIGHT TURN IND LEFT TURN IND
LEFT TURN SIGNAL LIGHT RELAY
LIGHTING SWITCH
LT GRN WIRE
ON OFF
ORG/ WIRE
ORG/BLK WIRE
POWER SOURCE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT
RIGHT TURN SIGNAL LIGHT RELAY
TAIL
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> COLUMN ECU TURN SIGNAL LIGHT
