Mitsubishi Galant IX (2003-2006) 2.4l: w/o electronic brake-force distribution, anti-lock braking system Wiring diagram
This page shows the only wiring diagram for the component.2.4l: w/o electronic brake-force distribution, anti-lock braking system, which is found in the car Mitsubishi Galant IX (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2.4l: w/o electronic brake-force distribution, anti-lock braking system (1 of 1)
2.4L: W/O ELECTRONIC BRAKE-FORCE DISTRIBUTION, ANTI-LOCK BRAKING SYSTEM
3.8L, 2.4L: W/ ELECTRONIC BRAKE-FORCE DISTRIBUTION, ANTI-LOCK BRAKING SYSTEM
A/C- ECU
ABS/TCL ECU (AT RIGHT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLK/YEL WIRE
COLUMN SWITCH
COMBINATION METER
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
ETACS-ECU
FRONT ECU (ON ENGINE COMPT RELAY BOX)
FUSE 10
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
JOINT CONNECTOR 2
JOINT CONNECTOR 3
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MIDDLE
MULTI CENTER DISPLAY UNIT
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SRS ECU (BEHIND LOWER CENTER OF DASH)
SUN ROOF ASSEMBLY
VIO WIRE
Go to component -> Computer data lines circuit -> 2.4L: W/O ELECTRONIC BRAKE-FORCE DISTRIBUTION, ANTI-LOCK BRAKING SYSTEM
