Mitsubishi Eclipse IV facelift (2008-2011) Charging circuit

2.4L (NEAR LEFT FRONT SHOCK TOWER) 3.8L BATTERY BLK/ YEL WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU/ BLK WIRE BLU/YEL WIRE COMBINATION METER ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 13 FUSE 2 FUSIBLE LINK 27 (ON BATTERY TERMINAL) FUSIBLE LINK 4 GENERATOR GENERATOR MALFUNCTION LIGHT IND GRN WIRE IGNITION SWITCH JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT END OF DASH) LOCK POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RUN WIRE STARTING CIRCUIT WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL/BLK WIRE
