Exterior lamps circuit for Mitsubishi Eclipse IV facelift (2008-2011)

BACKUP LAMPS CIRCUIT BLK WIRE BLU WIRE BLU/RED WIRE COUPE CRUISE CONTROL SYSTEM ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FRONT ECU FUSE 11 FUSE 14 FUSE 20 FUSE 21 FUSE 22 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HIGH MOUNTED STOPLIGHT HOT AT ALL TIMES JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT END OF DASH) LEFT FRONT COMBINATION LIGHT LEFT PARKING, SIDE MARKER LIGHT LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT LT GRN/BLK WIRE NCA WIRE ON OFF ORG/ WIRE ORG/BLK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT COMBINATION LIGHT RIGHT PARKING, SIDE MARKER LIGHT RIGHT REAR COMBINATION LIGHT STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT) TAILLIGHT RELAY VIO WIRE VIO/WHT WIRE W/ DISCHARGE TYPE HEADLIGHT W/ HALOGEN TYPE HEADLIGHT WHT WIRE YEL WIRE

BLK WIRE BLK/YEL WIRE BLU WIRE COLUMN ECU COLUMN SWITCH COMBINATION METER COMPUTER DATA LINES SYSTEM ETACS-ECU FUSE 2 FUSE 5 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD WARNING LIGHT SWITCH HEAD HOT IN ON HOT IN ON OR START JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT END OF DASH) LEFT LEFT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT FRONT TURN SIGNAL LIGHT LEFT TURN IND LEFT TURN SIGNAL LIGHT RELAY LIGHTING SWITCH LT GRN WIRE ON OFF ORG/ WIRE ORG/BLK WIRE POWER SOURCE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT TURN IND RIGHT TURN SIGNAL LIGHT RELAY TAIL TURN SIGNAL SWITCH VIO/WHT WIRE W/ DISCHARGE TYPE HEADLIGHT W/ HALOGEN TYPE HEADLIGHT WHT WIRE YEL WIRE
