Mitsubishi Eclipse IV facelift (2008-2011) passenger's side seat belt warning light Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's side seat belt warning light, in which he is found in the car Mitsubishi Eclipse IV facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger's side seat belt warning light (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU/YEL WIRE
C-123
C-202
C-215
C-216
COMBINATION METER
FIELD EFFECT TRANSISTOR FOR ILLUMINATION
FUSE 2
GLOVE BOX LIGHT
GRN WIRE
GRN/WHT WIRE
HOT IN ON OR START
ILL
ILLUMINATION (POINTER/DIAL FACE)
ILLUMINATION CONTROL BUTTON
JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT END OF DASH)
JUNCTION BLOCK (UNDER LEFT END OF DASH) FUSE 23
PASSENGER'S SIDE AIR BAG INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED/GRN WIRE
RED/WHT WIRE
SRS ECU (BEHIND LOWER CENTER OF DASH, NEAR CENTER REINFORCEMENT)
YEL/GRN WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> PASSENGER'S SIDE SEAT BELT WARNING LIGHT
Wiring diagram passenger's side seat belt warning light (2 of 2)
38 39 40 41 42 43 44 45 46 47 48 SIDE IMPACT INTERFACE GND
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
C-123
C-215
COMBINATION METER
CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF)
DATA
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
FUSE 2
FUSE 20 RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 3
GRN WIRE
GRN/WHT WIRE
HOT IN ON OR START
HOT WITH TAILLIGHT RELAY ENERGIZED ENGINE COMPARTMENT
ILLUMINATION LIGHT RELAY
INDICATOR DRIVE CKT 21 22 23 24 25 26
INDICATOR DRIVE CKT PNK WIRE
JOINT CONNECTOR
JOINT CONNECTOR 3
JUNCTION BLOCK (UNDER LEFT END OF DASH)
MICROCOMPUTER
OFF ON
OFF ON 33 34 DRIVER'S SIDE AIR BAG OFF DRIVE ON
OFF ON 36 37 DRIVER'S SIDE AIR BAG OFF DRIVE ON
OFF PASSENGER'S ON 27 28 SIDE AIR BAG OFF DRIVE ON
OFF PASSENGER'S ON 30 31 SIDE AIR BAG OFF DRIVE ON
PASSENGER'S SIDE AIR BAG OFF INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
POWER POWER
RED WIRE
RED/WHT WIRE
SIDE IMPACT INTERFACE
SRS ECU (BEHIND LOWER CENTER OF DASH, NEAR CENTER REINFORCEMENT)
SRS INDICATOR
W/ DISCHARGE TYPE HEADLIGHTS
W/ DISCHARGE TYPE HEADLIGHTS W/ HALOGEN TYPE HEADLIGHTS
W/ HALOGEN TYPE HEADLIGHTS
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PASSENGER'S SIDE SEAT BELT WARNING LIGHT
