Mitsubishi Eclipse IV facelift (2008-2011) hot with taillight relay energized engine compartment Wiring diagram
This page shows the only wiring diagram for the component.hot with taillight relay energized engine compartment, which is found in the car Mitsubishi Eclipse IV facelift (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot with taillight relay energized engine compartment (1 of 1)
38 39 40 41 42 43 44 45 46 47 48 SIDE IMPACT INTERFACE GND
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
C-123
C-215
COMBINATION METER
CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF)
DATA
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
FUSE 2
FUSE 20 RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 3
GRN WIRE
GRN/WHT WIRE
HOT IN ON OR START
HOT WITH TAILLIGHT RELAY ENERGIZED ENGINE COMPARTMENT
ILLUMINATION LIGHT RELAY
INDICATOR DRIVE CKT 21 22 23 24 25 26
INDICATOR DRIVE CKT PNK WIRE
JOINT CONNECTOR
JOINT CONNECTOR 3
JUNCTION BLOCK (UNDER LEFT END OF DASH)
MICROCOMPUTER
OFF ON
OFF ON 33 34 DRIVER'S SIDE AIR BAG OFF DRIVE ON
OFF ON 36 37 DRIVER'S SIDE AIR BAG OFF DRIVE ON
OFF PASSENGER'S ON 27 28 SIDE AIR BAG OFF DRIVE ON
OFF PASSENGER'S ON 30 31 SIDE AIR BAG OFF DRIVE ON
PASSENGER'S SIDE AIR BAG OFF INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
POWER POWER
RED WIRE
RED/WHT WIRE
SIDE IMPACT INTERFACE
SRS ECU (BEHIND LOWER CENTER OF DASH, NEAR CENTER REINFORCEMENT)
SRS INDICATOR
W/ DISCHARGE TYPE HEADLIGHTS
W/ DISCHARGE TYPE HEADLIGHTS W/ HALOGEN TYPE HEADLIGHTS
W/ HALOGEN TYPE HEADLIGHTS
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> HOT WITH TAILLIGHT RELAY ENERGIZED ENGINE COMPARTMENT
