Mitsubishi Eclipse IV facelift (2008-2011) front fog light switch front fog light tcl switch front fog light asc off switch Wiring diagram

2.4L 3.8L W/O ASC 3.8L W/ ASC 69 C-128 A/C ECU (INTEGRAL TO HEATER CONTROL UNIT) BLK WIRE BLK/PNK WIRE BLK/YEL WIRE C-117 C-19 C-20 21 31 C-20 C-19 30 22 COLUMN ECU COLUMN SWITCH DIMMER ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ETACS-ECU (UNDER LEFT SIDE OF DASH,ON JUNCTION BLOCK) FRONT ECU FRONT ECU (IN ENGINE COMPARTMENT RELAY BOX) FRONT FOG LIGHT SWITCH FRONT FOG LIGHT TCL SWITCH FRONT FOG LIGHT ASC OFF SWITCH FUSE 20 FUSE 22 FUSIBLE LINK 5 GRN/RED WIRE GRN/WHT WIRE HAZARD WARNING LIGHT SWITCH HEAD HEATED SEAT SWITCH HOT AT ALL TIMES ILLUMINATION LIGH RELAY JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (W/ HALOGEN TYPE) (UNDER LEFT END OF DASH) LIGHTING SWITCH MANUAL A/C AUTOMATIC A/C MULTI CENTER DISPLAY UNIT NCA WIRE RED/GRN WIRE RED/WHT WIRE SHIFT SWITCH ASSEMBLY (A/T: AT BASE OF SHIFT SELECTOR) TAIL TAILLIGHT RELAY VIO/WHT WIRE W/ DISCHARGE TYPE HEADLIGHT, 3.8L W/ HALOGEN TYPE HEADLIGHT
