Mitsubishi Eclipse IV facelift (2008-2011) door ind Wiring diagrams
This page contains all the electrical diagrams for the component. door ind, in which he is found in the car Mitsubishi Eclipse IV facelift (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door ind (1 of 3)
BLK WIRE
BLU WIRE
BLU/RED WIRE
COLUMN ECU KEY REMINDER SWITCH (IN STEERING COLUMN)
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR IND
DRIVER'S SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
FUSE 2
FUSE 22
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT END OF DASH)
LEFT DOOR SWITCH (AT LEFT "B" PILLAR)
LIGHTING SWITCH
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
RED WIRE
RED/WHT WIRE
SEAT BELT IND
TONE ALARM
WHT WIRE
Go to component -> Chime circuit -> DOOR IND
Wiring diagram door ind (2 of 3)
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
COUPE
DOOR IND
ETACS-ECU
FRONT DOME LIGHT
FULL LATCH SWITCH
FUSE 14
FUSE 2
FUSE 22
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HALF LATCH SWITCH
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
ILL
JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH)
KEY REMINDER SWITCH (IGNITION KEY HOLE ILLUMINATION LIGHT) (IN STEERING COLUMN)
LEFT DOOR LOCK ACTUATOR (INSIDE REAR OF LEFT DOOR)
LEFT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT VANITY MIRROR LIGHT
LIFTGATE LATCH SWITCH (COUPE)
LOCK
LT GRN WIRE
LUGGAGE COMPARTMENT LIGHT (COUPE)
NCA WIRE
NEAR PARKING BRAKE LEVER) POWER WINDOWS SYSTEM
ON ON DOOR OFF OFF OFF ON
PNK WIRE
REAR DOME LIGHT (COUPE)
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT VANITY MIRROR LIGHT
UNLOCK
W/ SUNROOF
W/O SUNROOF
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> DOOR IND
Wiring diagram door ind (3 of 3)
ANTI-LOCK IND
ANTI-THEFT SYSTEM
ASC OFF IND CPU
ASC/TCL IND
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (ON SIDE OF MASTER CYLINDER)
BRAKE IND
BRN/YEL WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND
DOOR IND
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE OIL PRESSURE SWITCH
FIELD EFFECT TRANSISTOR FOR ILLUMINATION
FOG IND
FUEL GAUGE
FUEL IND
FUSE 20
FUSE 22
FUSE 23
GENERATOR MALFUNCTION LIGHT IND
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT W/ TAILLIGHT RELAY ENERGIZED
ILLUMINATION CONTROL BUTTON
ILLUMINATION POINTER/ DIAL FACE
IMMOBILIZER IND
JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH)
LCD BACK LIGHT
LCD DISPLAY
LCD ODO/TRIP
LEFT TURN IND
MALFUNCTION IND
ODO/TRIP SWITCH
OIL IND
RED WIRE
RED/WHT WIRE
RIGHT TURN IND
SEAT BELT IND
SHIFT INDICATOR, TRANSMISSION FLUID TEMPERATURE INDICATOR
SPEEDOMETER
SRS IND
STARTING/CHARGING SYSTEM
TACHOMETER
TCL IND
TCL OFF IND
TEMP GAUGE
TIRE AIR IND
UPPER BEAM IND
WARNING SYSTEM
WHT/BLK WIRE
YEL/GRN WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> DOOR IND
