Mitsubishi Eclipse IV facelift (2008-2011) 2.4l w/ discharge type headlights, 3.8l Wiring diagram

2.4L 2.4L 3.8L 2.4L W/ DISCHARGE TYPE HEADLIGHTS, 3.8L 2.4L W/ HALOGEN TYPE HEADLIGHTS 3.8L A/C ECU (INTEGRAL TO HEATER CONTROL UNIT) A/C PRESSURE SENSOR (RIGHT SIDE OF ENGINE COMPARTMENT) AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER (BEHIND RIGHT SIDE OF DASH) AIR THERMO SENSOR (BEHIND CENTER OF DASH, ON HEATER UNIT) AMBIENT TEMPERATURE SENSOR (NEAR LOWER LEFT SIDE OF RADIATOR) BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE C-203 COMPT) CONDENSER FAN RELAY (2.4L) (LEFT FRONT OF ENGINE COMPT, IN RELAY BOX) DEFOGGER SYSTEM ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE FAN CONTROL RELAY (2.4L) (IN ENGINE COMPT RELAY BOX) FUSE 20 FUSE 22 FUSE 23 FUSE 5 FUSIBLE LINK 2 (2.4L) FUSIBLE LINK 26 GRN WIRE GRN/ WHT WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON JUNCTION BLOCK (2.4L) (UNDER LEFT END OF DASH) HOT W/ TAILLIGHT RELAY ENERGIZED ILLUMINATION LIGHT RELAY JOINT CONNECTOR 1 (2.4L) (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR 2 JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH) MODE SELECTION DAMPER CONTROL MOTOR, POTENTIOMETER (BEHIND LEFT SIDE OF DASH) NCA WIRE RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT) RADIATOR FAN RELAY (2.4L) (LEFT FRONT OF ENGINE COMPT, IN RELAY BOX) RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE VIO/YEL WIRE WHT GRN/ WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
