Mitsubishi Eclipse IV (2005-2008) passenger's side seat belt warning light Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's side seat belt warning light, in which he is found in the car Mitsubishi Eclipse IV (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
passenger's side seat belt warning light wiring diagram (1 of 2)
A/C ECU (INTEGRAL TO HEATER CONTROL UNIT)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BUTTON
C-117
C-117 RADIO, CD PLAYER
C-19 C-20 21 31
C-20 C-19 30 22
C-202
C-215
C-216
COLUMN ECU
COLUMN SWITCH
COMBINATION METER
CONTROL ILLUMINATION
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FRONT ECU
FRONT FOG LIGHT SWITCH
FUSE 2
FUSE 20
FUSIBLE LINK 5
GLOVE BOX LIGHT
GRN WIRE
GRN/WHT WIRE
HAZARD WARNING LIGHT SWITCH
HEAD
HEATED SEAT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION
ILLUMINATION (POINTER/DIAL FACE)
JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 2
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH)
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH) FUSE 23
LIGHTING SWITCH
MANUAL A/C AUTOMATIC A/C
MULTI CENTER DISPLAY UNIT
PASSENGER'S SIDE AIR BAG INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
SHIFT SWITCH ASSEMBLY (A/T: AT BASE OF SHIFT SELECTOR)
SRS ECU (BEHIND LOWER CENTER OF DASH, NEAR CENTER REINFORCEMENT)
TAIL
TAILLIGHT RELAY
TCL SWITCH
TRANSISTOR FOR FEELD EFFECT
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> PASSENGER'S SIDE SEAT BELT WARNING LIGHT
passenger's side seat belt warning light wiring diagram (2 of 2)
38 39 40 41 42 43 44 45 46 47 48 SIDE IMPACT INTERFACE GND
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLU WIRE
BLU/YEL WIRE
C-04
C-123
C-215
COMBINATION METER
CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF)
DATA
DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH)
ENGINE COMPT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 2
FUSE 20
FUSE 22
FUSE 3
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT WITH TAILLIGHT RELAY ENERGIZED
INDICATOR DRIVE CKT 21 22 23 24 25 26
INDICATOR DRIVE CKT PNK WIRE
J/C 1
J/C 2
J/C 3
JUNCTION BLOCK (LEFT END OF DASH)
MICROCOMPUTER
OFF ON 27 28 AIR BAG DRIVE OFF ON
OFF ON 30 31 AIR BAG DRIVE OFF ON
OFF ON 33 34 AIR BAG DRIVE OFF ON
OFF ON 36 37 AIR BAG DRIVE OFF ON
ON OFF
PASSENGER'S SIDE AIR BAG OFF INDICATOR LIGHT
PASSENGER'S SIDE SEAT BELT WARNING LIGHT
PNK WIRE
POWER POWER
RED WIRE
SIDE IMPACT INTERFACE
SRS ECU (BEHIND CENTER OF DASH)
SRS INDICATOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PASSENGER'S SIDE SEAT BELT WARNING LIGHT
