Mitsubishi Eclipse IV (2005-2008) heated seat relay Wiring diagram
This page shows the only wiring diagram for the component.heated seat relay, which is found in the car Mitsubishi Eclipse IV (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated seat relay (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 5
FUSE 7
GRN WIRE
HEATED SEAT RELAY
HEATED SEAT SWITCH
HEATER
HI LO OFF OFF
HOT AT ALL TIMES
HOT IN ON
ILLUM
IND
J/C 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH)
LEFT
LEFT HEATED SEAT ASSEMBLY (UNDER DRIVER'S SEAT)
LO ILLUM
LT GRN WIRE
NCA WIRE
OFF LO HI
RED WIRE
RIGHT
RIGHT HEATED SEAT ASSEMBLY (UNDER FRONT PASSENGER'S SEAT)
SEAT BACK HEATER
SEAT CUSHION HEATER
THERMO- STAT
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> HEATED SEAT RELAY
