Mitsubishi Eclipse IV (2005-2008) feild effect transistor for illumination Wiring diagram
This page shows the only wiring diagram for the component.feild effect transistor for illumination, which is found in the car Mitsubishi Eclipse IV (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram feild effect transistor for illumination (1 of 1)
ANTI-LOCK IND
ANTI-THEFT SYSTEM
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (ON SIDE OF MASTER CYLINDER)
BRAKE IND
BRN/YEL WIRE
BUTTON
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CRUISE IND
DOOR IND
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE OIL PRESSURE SWITCH (2.4L: LOWER RIGHT SIDE OF ENGINE)
FEILD EFFECT TRANSISTOR FOR ILLUMINATION
FOG IND
FUEL GAUGE
FUEL IND
FUSE 20
FUSE 22
FUSE 23
GENERATOR MALFUNCTION LIGHT
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT W/ TAILLIGHT RELAY ENERGIZED
ILLUMINATION CONTROL
ILLUMINATION POINTER/ DIAL FACE
IMMOBILIZER IND
JOINT CONNECTOR 2 (BEHIND LEFT SIDE OF DASH)
LCD BACK LIGHT
LCD DISPLAY
LCD ODO/TRIP
LEFT TURN IND
MALFUNCTION IND
ODO/TRIP SWITCH
OIL IND
PARKING BRAKE SWITCH
RED WIRE
RED/WHT WIRE
RIGHT TURN IND
SEAT BELT IND
SHIFT INDICATOR, TRANSMISSION FLUID TEMPERATURE INDICATOR
SPEED METER
SRS IND
STARTING/CHARGING SYSTEM
TACHOMETER
TCL IND
TCL OFF IND
TEMP GAUGE
UPPER BEAM IND
WARNING SYSTEM
WHT/BLK WIRE
YEL/GRN WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> FEILD EFFECT TRANSISTOR FOR ILLUMINATION
