Mitsubishi Eclipse IV (2005-2008) engine control module (m/t) powertrain Wiring diagrams
This page contains all the electrical diagrams for the component. engine control module (m/t) powertrain, in which he is found in the car Mitsubishi Eclipse IV (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
engine control module (m/t) powertrain wiring diagram (1 of 2)
1 2 3 A-22
1 2 A-22-1
2.4L
2.4L 3.8L
3.8L
5 10 B-18
69 B-20
93 B-21
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
CONDENSER FAN MOTOR (LEFT FRONT OF ENGINE COMPARTMENT)
CONDENSER FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
CONDENSER FAN RELAY (LEFT FRONT OF ENGINE COMPARTMENT, IN RELAY BOX)
CONTROL MODULE (A/T) (LEFT SIDE OF ENGINE COMPARTMENT, FORWARD OF RELAY BOX)
COOLING FAN SHROUD)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (M/T) POWERTRAIN
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (2.4L: ON REAR OF ENGINE, NEAR COOLANT OUTLET)
FAN CONTROL MODULE (ATTACHED TO
FAN CONTROL RELAY (IN ENGINE COMPARTMENT RELAY BOX)
FUSE 5
FUSIBLE LINK 2
FUSIBLE LINK 26
HOT AT ALL TIMES
HOT IN ON
JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (UNDER LEFT END OF DASH)
NCA WIRE
RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPARTMENT)
RADIATOR FAN RELAY (LEFT FRONT OF ENGINE COMPARTMENT, IN RELAY BOX)
RED WIRE
RED/WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/GRN WIRE
Go to component -> Cooling fan circuit -> ENGINE CONTROL MODULE (M/T) POWERTRAIN
engine control module (m/t) powertrain wiring diagram (2 of 2)
