Car Wiring Diagrams for Trunk, tailgate, fuel door circuit for Mitsubishi Eclipse III (1999-2005)

BLK WIRE BLU WIRE DEDICATED FUSE 14 DEDICATED FUSE 23 ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ETACS-ECU GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH) MULTI- PURPOSE FUSE 10 MULTI- PURPOSE FUSE 23 RED WIRE TRUNK LID LATCH SWITCH TRUNK LID OPENER ACTUATOR (AT LEFT FRONT CORNER OF TRUNK) WHT WIRE WHT/BLK WIRE
