Wiring diagram engine performance 3.0l, with m/t for Mitsubishi Eclipse III (1999-2005)

A/C SYSTEM A/C SYSTEM COOLING FANS SYSTEM BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE DISTRIBUTOR DISTRIBUTOR ASSEMBLY ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE SPEED DETECTION CONNECTOR (IN ENGINE COMPT RELAY BOX) FUEL INJECTORS FUSE 9 GENERATOR GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES IDLE AIR CONTROL MOTOR (BELOW THROTTLE BODY) IGNITION COIL INSTRUMENT CLUSTER SYSTEM LT GRN WIRE NCA NCA WIRE NCA WIRE POWER TRANS- ISTOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM TO SPARK PLUGS TOP DEAD CENTER SENSOR VARIABLE INDUCTION CONTROL SOLENOID (W/ VIC) (RIGHT REAR CORNER OF ENGINE COMPT) WHT WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMBINATION METER ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (ON REAR CENTER OF ENGINE) FUEL PUMP MODULE FUEL PUMP RELAY #1 FUEL PUMP RELAY 2 FUEL TANK DIFFERENTIAL PRESSURE SENSOR (ON TOP OF FUEL TANK) FUSE 17 FUSE 24 FUSE 24 FUSE 23 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE HEATED OXYGEN SENSOR, REAR HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER ECU J/C 2 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (ON LEFT END OF DASH) MALFUNCTION INDICATOR LAMP (MIL) MANIFOLD DIFFERENTIAL PRESSURE SENSOR (ON RIGHT SIDE OF INTAKE MANIFOLD) NCA WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE THROTTLE POSITION SENSOR (ON THROTTLE BODY) VEHICLE SPEED SENSOR (LEFT SIDE OF ENGINE COMPT, ON TRANSAXLE) VOLUME AIRFLOW SENSOR (LEFT SIDE OF ENGINE COMPT, ON AIR CLEANER) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE

A/C SYSTEM ANTI-THEFT SYSTEM (IMMOBILIZER ECU) AUTO CRUISE CONTROL ECU (BEHIND CENTER OF DASH) BLK WIRE BLK/ORG WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CRANKSHAFT POSITION SENSOR (ON LOWER FRONT OF ENGINE, NEAR CRANKSHAFT) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/RED WIRE GRY/GRN WIRE INSTRUMENT CLUSTER SYSTEM J/C 1 (BEHIND LEFT SIDE OF DASH) KNOCK SENSOR (UNDER CENTER OF INTAKE MANIFOLD) PNK/BLK WIRE POWER STEERING PRESSURE SWITCH (ON POWER STEERING PUMP) RED WIRE RED/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
