Mitsubishi Eclipse III (1999-2005) 3.0l, manual a/c circuit

A/C SWITCH AIR THERMO SENSOR AUTOMATIC COMPRESSOR CONTROLLER (BEHIND RIGHT SIDE OF DASH) BACK OF HEATER CONTROL PANEL) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH, ON BLOWER RELAY BLOWER RESISTOR (BEHIND RIGHT SIDE OF DASH, NEAR BLOWER MOTOR) BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CONDENSER FAN MOTOR FAN CONTROLLER (ATTACHED TO COOLING FAN SHROUD) FUSE 20 FUSE 6 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON HVAC UNIT) ILLUM INSIDE JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH) LT BLU WIRE MAXIMUM COOLING RELAY MAXIMUM COOLING TEMPERATURE SWITCH NCA WIRE OFF IND OFF LO ML MH ORG/ WIRE OUTSIDE IND PNK WIRE RADIATOR FAN MOTOR RED WIRE RED/WHT WIRE RED/YEL WIRE THERMISTOR SENSOR (BEHIND CENTER OF DASH, ON HEATER UNITY) WATER SHUT MOTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT) WATER SHUT VALVE CONTROLLER (COUPE) (BEHIND CENTER OF DASH, ON WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

A/C COMPRESSOR ASSEMBLY A/C COMPRESSOR RELAY A/C REFRIGERANT TEMPERATURE SENSOR A/T BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE COMBINATION METER DEFROSTER SWITCH DISTRIBUTOR ASSEMBLY DUAL PRESSURE SWITCH (BEHIND RIGHT HEADLIGHT, ON RECEIVER DRIER) ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROLS SYSTEM ENGINE SPEED DETECTION CONNECTOR (IN ENGINE COMPARTMENT RELAY BOX) FAN CONTROL RELAY FOOT/ DEF FUSE 10 FUSE 9 FUSIBLE LINK 2 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES LOCK SENSOR M/T MAGNETIC CLUTCH MFI RELAY OFF ON ON-OFF: 200 KPA (28 PSI) OFF-ON: 220 KPA (32 PSI) ON-OFF: 3140 KPA (455 PSI) OFF-ON: 2550 KPA (370 PSI) ORG/ WIRE PNK WIRE RED WIRE RED/WHT WIRE WHT WIRE WHT/VIO WIRE YEL WIRE
