Mitsubishi Eclipse III (1999-2005) water shut motor (behind right side of Wiring diagram
This page shows the only wiring diagram for the component.water shut motor (behind right side of, which is found in the car Mitsubishi Eclipse III (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram water shut motor (behind right side of (1 of 1)
A/C SWITCH
AIR THERMO SENSOR
AUTOMATIC COMPRESSOR CONTROLLER (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT)
BLOWER RELAY
BLOWER RESISTOR (BEHIND RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
CONDENSER FAN MOTOR
DASH, ON HVAC UNIT)
FAN CONTROLLER (ATTACHED TO COOLING FAN SHROUD)
FUSE 20
FUSE 6
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
ILLUM
INSIDE
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH)
MAXIMUM COOLING RELAY
MAXIMUM COOLING TEMPERATURE SWITCH
NCA WIRE
OFF IND
OFF LO ML MH
ORG/ WIRE
OUTSIDE IND
OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL MOTOR (BEHIND RIGHT
RADIATOR FAN MOTOR
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
THERMISTOR SENSOR (BEHIND CENTER OF DASH, ON HEATER UNIT)
WATER SHUT MOTOR (BEHIND RIGHT SIDE OF
WATER SHUT VALVE CONTROLLER (COUPE)
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.4l, manual a/c circuit (1 of 2) -> WATER SHUT MOTOR (BEHIND RIGHT SIDE OF
