Mitsubishi Eclipse III (1999-2005) torque converter control low/ reverse Wiring diagrams

1 IND 2 IND 2.4L 3.0L 3 IND 4 IND A/T CONTROL RELAY (IN ENGINE COMPT RELAY BOX) A/T CONTROL SOLENOID VALVE (ON TOP OF TRANSAXLE) A/T OIL TEMP AUTO BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-112 COMBINATION METER CRANKSHAFT POSITION SENSOR (LOWER FRONT OF ENGINE, NEAR CRANKSHAFT) CRUISE CONTROL SYSTEM D IND ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMP SENSOR (REAR OF ENGINE, NEAR COOLANT OUTLET) FUSE 11 FUSE 15 FUSE 22 FUSE 9 GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START INPUT SHAFT SPEED SENSOR (ON TRANSAXLE) J/C 1 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT END OF DASH) MFI RELAY (IN ENGINE COMPT RELAY BOX) N IND ORG/BLK WIRE OUPUT SHAFT SPEED SENSOR (ON TRANSAXLE) OVER DRIVE SECOND UNDER DRIVE P IND PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) R IND RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SHIFT SWITCH SHIFT SWITCH ASSEMBLY SPORT STARTING/ CHARGING SYSTEM STOPLIGHT SWITCH (ON BRAKE PEDAL SUPPORT) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TORQUE CONVERTER CONTROL LOW/ REVERSE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/C SYSTEM A/T CONTROL RELAY (ON ENGINE COMPT RELAY BOX) A/T CONTROL SOLENOID VALVE ASSEMBLY (ON TOP OF TRANSAXLE) A/T FLUID TEMP BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES DEDICATED FUSE 15 HOT IN RUN OR START INSTRUMENT CLUSTER SYSTEM J/C 1 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (ON LEFT END OF DASH) MULTI- PURPOSE FUSE 22 KNOCK SENSOR (ON SIDE OF ENGINE BLOCK) OUTPUT SHAFT SPEED SENSOR (ON TRANSAXLE) INPUT SHAFT SPEED SENSOR (ON TRANSAXLE) OVER DRIVE SECOND UNDER DRIVE PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) PNK/BLK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM STOPLIGHT SWITCH (ON BRAKE PEDAL SUPPORT) TORQUE CONVERTER CONTROL LOW/ REVERSE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

A/C SYSTEM A/T CONTROL RELAY (ON ENGINE COMPT RELAY BOX) A/T CONTROL SOLENOID VALVE ASSEMBLY (ON TOP OF TRANSAXLE) A/T FLUID TEMP BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES DEDICATED FUSE 15 HOT IN RUN OR START INSTRUMENT CLUSTER SYSTEM JUNCTION BLOCK (ON LEFT END OF DASH) MULTI- PURPOSE FUSE 22 KNOCK SENSOR (ON SIDE OF ENGINE BLOCK) OUTPUT SHAFT SPEED SENSOR (ON TRANSAXLE) INPUT SHAFT SPEED SENSOR (ON TRANSAXLE) OVER DRIVE SECOND UNDER DRIVE PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) PNK/BLK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM STOPLIGHT SWITCH (ON BRAKE PEDAL SUPPORT) TORQUE CONVERTER CONTROL LOW/ REVERSE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE

A/C SYSTEM A/T CONTROL RELAY (IN ENGINE COMPT RELAY BOX) A/T CONTROL SOLENOID VALVE ASSEMBLY (ON TOP OF TRANSAXLE) A/T OIL TEMP BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) EXTERIOR LIGHTS SYSTEM, WIPER/ WASHER SYSTEM FUSE 11 FUSE 15 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN RUN OR START IMMOBILIZER ECU INPUT SHAFT SPEED SENSOR (ON TRANSAXLE) INSTRUMENT CLUSTER SYSTEM JUNCTION BLOCK (ON LEFT END OF DASH) FUSE 22 KNOCK SENSOR (UNDER CENTER OF INTAKE MANIFOLD) OUTPUT SHAFT SPEED SENSOR (ON TRANSAXLE) OVER DRIVE SECOND UNDER DRIVE PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) PNK/BLK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM STOPLIGHT SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT) TORQUE CONVERTER CONTROL LOW/ REVERSE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE
