Mitsubishi Eclipse III (1999-2005) off up Wiring diagram
This page shows the only wiring diagram for the component.off up, which is found in the car Mitsubishi Eclipse III (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off up (1 of 1)
AUTO DOWN ON
BLK WIRE
BLU WIRE
DOWN
ETACS-ECU
FUSE 22
FUSE 23
FUSIBLE LINK 5
GRN WIRE
GRN/BLK WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
JOINT CONNECTOR 2
JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH)
LEFT
LEFT DOOR SWITCH
LEFT POWER WINDOW MOTOR
LOCK SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
OFF
OFF DOWN
OFF UP
ON OFF
ON OFF UP
ON UP
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
POWER WINDOW SUB-SWITCH
RED/BLK WIRE
RED/WHT WIRE
RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
RIGHT
RIGHT DOOR SWITCH
RIGHT POWER WINDOW MOTOR
YEL WIRE
Go to component -> Power windows circuit, coupe -> OFF UP
