Mitsubishi Eclipse III (1999-2005) off on off on Wiring diagram
This page shows the only wiring diagram for the component.off on off on, which is found in the car Mitsubishi Eclipse III (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off on off on (1 of 1)
1 2 C-72
5 6 AIR BAG DRIVE CIRCUIT
7 8 AIR BAG DRIVE CIRCUIT
9 10 11 12 13 14 15 16 IGNITION
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
C-72
CLOCK- SPRING
CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF)
DATA C-72
DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW LEFT SIDE OF DASH)
DETECTION CIRCUIT
DRIVER'S SIDE AIR BAG MODULE SQUIB
GRN WIRE
GRN/YEL WIRE
GROUND
IGNITION
J/C 1 (BEHIND LEFT KICK PANEL)
NCA WIRE
OFF ON
OFF ON OFF ON
ON OFF
PASSENGER'S SIDE AIR BAG MODULE SQUIB
RED WIRE
RED/WHT WIRE
RIGHT SIDE AIR BAG MODULE (SQUIB)
SRS ECU (BEHIND LOWER CENTER OF DASH, NEAR CENTER REINFORCEMENT)
WARNING LIGHT
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit, with side airbag (1 of 2) -> OFF ON OFF ON
