Mitsubishi Eclipse III (1999-2005) motor antenna Wiring diagrams

BLK WIRE BLK/WHT WIRE DEDICATED FUSE 22 DEDICATED FUSE 23 ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START JOINT CONNECTOR 2 JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH) MOTOR ANTENNA MOTOR ANTENNA ASSEMBLY (ON LEFT SIDE OF LUGGAGE COMPT) MOTOR ANTENNA ECU MULTI- PURPOSE FUSE 23 NCA WIRE PNK WIRE RADIO, TAPE PLAYER, CD CHANGER RED WIRE RED/WHT WIRE WHT WIRE WHT/BLK WIRE

AMPLIFIER BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CD AUTO CHANGER CENTER SPEAKER CLOCK- SPRING DEDICATED FUSE 1 DEDICATED FUSE 22 DEDICATED FUSE 23 DIN CABLE ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) DEDICATED FUSE 23 GLASS ANTENNA (IF EQUIPPED) GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/RED WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START JOINT CONNECTOR 2 JUNCTION BLOCK (J/B) (UNDER LEFT END OF DASH) LEFT DOOR SPEAKER LEFT REAR SPEAKER LEFT REMOTE CONTROLLED RADIO SWITCH LEFT TWEETER MOTOR ANTENNA MOTOR ANTENNA ASSEMBLY (IF EQUIPPED) (ON LEFT SIDE OF LUGGAGE COMPARTMENT) MOTOR ANTENNA ECU MULTI CENTER DISPLAY UNIT NCA WIRE ON OFF ON ON OFF ORG/BLU WIRE ORG/RED WIRE PNK WIRE RADIO, TAPE PLAYER, CD CHANGER RED WIRE RED/WHT WIRE RIGHT DOOR SPEAKER RIGHT REAR SPEAKER RIGHT REMOTE CONTROLLED RADIO SWITCH RIGHT TWEETER WHIP ANTENNA (IF EQUIPPED) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL/BLU WIRE YEL/RED WIRE
