Anti-theft circuit for Mitsubishi Eclipse II (1994-1999)

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DEDICATED FUSE 11 DOOR LOCKS SYSTEM ETACS-ECU GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOOD SWITCH HOT AT ALL TIMES HOT IN RUN OR START INTERIOR LIGHTS SYSTEM (DOME LIGHT) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT DOOR LOCK ACTUATOR SWITCH (INSIDE DOOR) LEFT DOOR LOCK SWITCH LIFTGATE KEY CYLINDER SWITCH LIFTGATE SWITCH LT GRN WIRE LT GRN/BLK WIRE MULTI- PURPOSE FUSE 8 NCA WIRE ORG/ WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT DOOR LOCK ACTUATOR SWITCH (INSIDE DOOR) RIGHT DOOR LOCK SWITCH SECURITY INDICATOR STARTING/ CHARGING SYSTEM (THEFT-ALARM STARTER RELAY)

ANTENNA BLK WIRE BLK/BLU WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DEDICATED FUSE 12 DIODE DIODE (BEHIND LEFT SIDE OF DASH) ENGINE CONTROLS SYSTEM ANTI-LOCK BRAKES SYSTEM GRN/BLK WIRE GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM (HEADLIGHT RELAY) HORNS SYSTEM (HORN RELAY) HOT AT ALL TIMES INTERIOR LIGHTS SYSTEM (FOOT LIGHTS) J/C 1 (BEHIND LEFT SIDE OF DASH) J/C 2 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) KEY REMINDER SWITCH LEFT DOOR LOCK KEY CYLINDER SWITCH LEFT DOOR SWITCH LT GRN WIRE MULTI- PURPOSE FUSE 5 NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DOOR LOCK KEY CYLINDER SWITCH RIGHT DOOR SWITCH STARTING/CHARGING SYSTEM (THEFT-ALARM STARTER RELAY) THEFT-ALARM HORN RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX) YEL WIRE
