Mitsubishi Eclipse II (1994-1999) 2.4l, a/c circuit

1995 VFTC 7 B-50 A/C SWITCH A/C SWITCH ILLUMINATION AUTOMATIC COMPRESSOR ECM (BELOW RIGHT SIDE OF I/P) B-49 BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLOWER RESISTOR (BEHIND RIGHT SIDE OF I/P) BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE DEFROSTER SWITCH DUAL PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPARTMENT) FIN THERMO SENSOR (IN PLENUM BELOW RIGHT SIDE OF I/P) FUSE 11 FUSE 13 FUSIBLE LINK 7 GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN RUN IGNITION SWITCH JUNCTION BLOCK (BELOW LEFT SIDE OF I/P) LOCK ML LO MH HI ML LO MH OFF OFF HI NCA WIRE OFF ORG/ WIRE RED/BLK WIRE RED/BLU WIRE RUN WIRE UNDERHOOD FUSE/RELAY BOX 2 (RIGHT REAR OF ENGINE COMPARTMENT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE

1995 VFTC A/C COMPRESSOR A/C COMPRESSOR CLUTCH RELAY (RIGHT SIDE OF ENGINE COMPARTMENT) A/C REFRIGERANT TEMPERATURE SWITCH (ON COMPRESSOR) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE CONDENSER FAN MOTOR CONDENSER FAN RELAY (HI) (RIGHT SIDE OF ENGINE COMPARTMENT) CONDENSER FAN RELAY (LO) (RIGHT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROL MODULE (CENTER OF I/P) ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE) FUSE 8 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE HOT AT ALL TIMES J/C 2 M/T A/T RADIATOR FAN RADIATOR FAN MOTOR RADIATOR FAN RELAY (HI) (RIGHT SIDE OF ENGINE COMPARTMENT) RADIATOR FAN RELAY (LO) (RIGHT SIDE OF ENGINE COMPARTMENT) RED/BLK WIRE RED/BLU WIRE UNDERHOOD FUSE/RELAY BOX 1 (RIGHT REAR OF ENGINE COMPARTMENT) FUSE 9 VEHICLE SPEED SENSOR (ON TRANSAXLE) WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
