Mitsubishi Eclipse II (1994-1999) starter motor Wiring diagrams
This page contains all the electrical diagrams for the component. starter motor, in which he is found in the car Mitsubishi Eclipse II (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram starter motor (1 of 9)
1 3 (1996-97) (1998-99)
2 3 (1996-97) (1998-99)
BATTERY
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CRUISE CONTROL SYSTEM ENGINE CONTROLS SYSTEM
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENG COMPT)
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
FUSIBLE LINK 4
HOT AT ALL TIMES
IGNITION SWITCH
J/C 4 (LEFT FRONT OF ENG COMPT)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANSAXLE)
TRANSMISSION SYSTEM
Go to component -> 2.0l, starting circuit, a/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (2 of 9)
2 3 (1997) (1998-99)
2.0L NON-TURBO
2.0L TURBO
2.0L TURBO 2.4L
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE CONTROLS SYSTEM
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
YEL WIRE
Go to component -> 2.0l, starting circuit, m/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (3 of 9)
1 3 (1996-97) (1998-99)
2 3 (1996-97) (1998-99)
3 4 (1996-97) (1998-99)
A/T ONLY
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
CRUISE CONTROL SYSTEM, ENGINE CONTROL SYSTEM
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENG COMPT)
FUSIBLE LINK 4
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
J/C 4 (LEFT FRONT OF ENG COMPT)
M/T ONLY (LEFT REAR OF ENG, NEAR STARTER MOTOR)
NCA WIRE
OFF
RED/BLK WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANS- AXLE)
W/ A/T
W/ M/T
YEL WIRE
Go to component -> 2.0l, starting circuit, without anti-theft -> STARTER MOTOR
Wiring diagram starter motor (4 of 9)
2 3 (1997) (1998-99)
3 1 (1997) (1998-99)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CRUISE CONTROL SYSTEM ENGINE CONTROLS SYSTEM
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENG COMPT)
ENGINE CONTROLS SYSTEM
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
HOT AT ALL TIMES
IGNITION SWITCH
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF ENG COMPT, ON TRANS- AXLE)
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
Go to component -> 2.0l turbo, starting circuit, a/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (5 of 9)
2 3 (1997) (1998-99)
2.0L NON-TURBO
2.0L TURBO
2.0L TURBO 2.4L
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE CONTROLS SYSTEM
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
YEL WIRE
Go to component -> 2.0l turbo, starting circuit, m/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (6 of 9)
1 3 (1997) (1998-99)
2 3 (1997) (1998-99)
3 1 (1997) (1998-99)
7 8 (2.0L TURBO) (2.4L)
A/T
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM CRUISE CONTROL SYSTEM
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
M/T
NCA WIRE
OFF
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
W/ A/T
W/ M/T
YEL WIRE
Go to component -> 2.0l turbo, starting circuit, without anti-theft -> STARTER MOTOR
Wiring diagram starter motor (7 of 9)
2 3 (1997) (1998-99)
3 1 (1997) (1998-99)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CRUISE CONTROL SYSTEM ENGINE CONTROLS SYSTEM
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENG COMPT)
ENGINE CONTROLS SYSTEM
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
HOT AT ALL TIMES
IGNITION SWITCH
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF ENG COMPT, ON TRANS- AXLE)
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
Go to component -> 2.4l, starting circuit, a/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (8 of 9)
2 3 (1997) (1998-99)
2.0L NON-TURBO
2.0L TURBO
2.0L TURBO 2.4L
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ENGINE CONTROLS SYSTEM
ETACS ECU (BEHIND LEFT SIDE OF DASH, ON JUNCTION BLOCK)
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY REMINDER SWITCH
LT GRN/BLK WIRE
NCA WIRE
OFF
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
THEFT ALARM STARTER RELAY (BEHIND LEFT SIDE OF DASH, ON INTERIOR RELAY BOX)
YEL WIRE
Go to component -> 2.4l, starting circuit, m/t with anti-theft -> STARTER MOTOR
Wiring diagram starter motor (9 of 9)
1 3 (1997) (1998-99)
2 3 (1997) (1998-99)
3 1 (1997) (1998-99)
7 8 (2.0L TURBO) (2.4L)
A/T
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM CRUISE CONTROL SYSTEM
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
M/T
NCA WIRE
OFF
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
W/ A/T
W/ M/T
YEL WIRE
Go to component -> 2.4l, starting circuit, without anti-theft -> STARTER MOTOR
