Mitsubishi Eclipse II (1994-1999) slow fast variable intermittent wiper control switch Wiring diagram
This page shows the only wiring diagram for the component.slow fast variable intermittent wiper control switch, which is found in the car Mitsubishi Eclipse II (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slow fast variable intermittent wiper control switch (1 of 1)
2.0L NON-TURBO
2.0L TURBO 2.4L
BLK WIRE
BLU WIRE
COLUMN SWITCH
COMBIN- ATION METER WASHER INDICATOR
EXCEPT 2.0L NON-TURBO
GRN WIRE
HI OFF LO INT
HI OFF LO LO INT INT
HOT IN ACC OR RUN
HOT IN RUN OR START
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MULTI- PURPOSE FUSE 8
MULTI- PURPOSE FUSE 9
NCA WIRE
ORG/ WIRE
SLOW FAST VARIABLE INTERMITTENT WIPER CONTROL SWITCH
SOLID STATE
WHT WIRE
WIND- SHIELD WASHER SWITCH
WINDHIELD WIPER SWITCH
WINDSHIELD INTERMITTENT WIPER RELAY
YEL WIRE
Go to component -> Front wiper/washer circuit -> SLOW FAST VARIABLE INTERMITTENT WIPER CONTROL SWITCH
