Mitsubishi Eclipse II (1994-1999) motor antenna control relay Wiring diagram
This page shows the only wiring diagram for the component.motor antenna control relay, which is found in the car Mitsubishi Eclipse II (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram motor antenna control relay (1 of 1)
ALL OTHERS
BLK WIRE
BLU WIRE
DEDICATED FUSE 11
DEDICATED FUSE 12
ECLIPSE SPYDER NON-TURBO (W/ AMPLIFIER)
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN ON OR START
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MOTOR ANTENNA ASSEMBLY
MOTOR ANTENNA CONTROL RELAY
MULTI- PURPOSE FUSE 8
NCA WIRE
RADIO WITH TAPE PLAYER
RED WIRE
W/ KEYLESS ENTRY, ECLIPSE SPYDER
W/O KEYLESS ENTRY
WHT WIRE
WHT/BLK WIRE
Go to component -> Power antenna circuit -> MOTOR ANTENNA CONTROL RELAY
