Mitsubishi Eclipse II (1994-1999) liftgate switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate switch, in which he is found in the car Mitsubishi Eclipse II (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate switch (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DEDICATED FUSE 11
DOOR LOCKS SYSTEM
ETACS-ECU
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOOD SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
INTERIOR LIGHTS SYSTEM (DOME LIGHT)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR LOCK ACTUATOR SWITCH (INSIDE DOOR)
LEFT DOOR LOCK SWITCH
LIFTGATE KEY CYLINDER SWITCH
LIFTGATE SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
MULTI- PURPOSE FUSE 8
NCA WIRE
ORG/ WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT DOOR LOCK ACTUATOR SWITCH (INSIDE DOOR)
RIGHT DOOR LOCK SWITCH
SECURITY INDICATOR
STARTING/ CHARGING SYSTEM (THEFT-ALARM STARTER RELAY)
Go to component -> Anti-theft circuit (1 of 2) -> LIFTGATE SWITCH
Wiring diagram liftgate switch (2 of 2)
BLK WIRE
BLK/BLU (OR WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
COMBINATION METER
CONVERTIBLE TOP
DATA LINK CONNECTOR (PARTIAL) (BELOW LEFT SIDE OF DASH)
DEDICATED FUSE 11
DEDICATED FUSE 5
DIODE (BEHIND LEFT SIDE OF DASH, TAPED TO HARNESS)
DOME LIGHT
DOOR
DOOR LOCKS SYSTEM (KEYLESS ENTRY SYSTEM)
DOOR LOCKS, SOUND SYSTEMS
ECLIPSE
ECLIPSE SPYDER
ECLIPSE SPYDER ECLIPSE
ECLIPSE SPYDER, ECLIPSE W/ SUNROOF
ECLIPSE W/O SUNROOF
GLOVE COMPARTMENT LIGHT
GLOVE COMPARTMENT LIGHT SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HOT W/COLUMN SWITCH (LIGHTING SWITCH) IN HEAD OR TAIL POSITION
IGNITION KEYHOLE ILLUMINATION LIGHT (PART OF KEY REMINDER SWITCH)
J/C 1 (LEFT SIDE OF DASH)
J/C 2 (LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT SIDE DOOR SWITCH
LIFTGATE SWITCH
LUGGAGE COMPARTMENT LIGHT
LUGGAGE COMPARTMENT LIGHT SWITCH (W/O ANTI-THEFT)
MULTI- PURPOSE FUSE 8
NCA WIRE
OR ETACS-ECU
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT SIDE DOOR SWITCH
RIGHT SIDE FOOT LIGHT LEFT SIDE FOOT LIGHT
RIGHT VANITY MIRROR LIGHT
UNIVERSAL GARAGE DOOR OPENER (FRONT END OF ROOF)
W/ ANTI- THEFT
W/ANTI- THEFT W/O ANTI- THEFT
W/ANTI-THEFT
W/O ANTI- THEFT
W/UNIVERSAL GARAGE DOOR OPENER
WHT WIRE
Go to component -> Courtesy lamps circuit -> LIFTGATE SWITCH
