Mitsubishi Eclipse II (1994-1999) if not equipped Wiring diagram
This page shows the only wiring diagram for the component.if not equipped, which is found in the car Mitsubishi Eclipse II (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram if not equipped (1 of 1)
1 3 2 CD AUTO CHANGER CONNECTOR
1996 VFTC
ANTENNA
ANTENNA MOTOR CONTROL RELAY
BLK (OR WHT/BLU) WIRE
BLK (OR WHT/RED) WIRE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT (BLK/RED) WIRE
BLK/WHT (OR BLK/BLU) WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
DEDICATED FUSE 11
DEDICATED FUSE 12
DIN CABLE
DOOR LOCK SYSTEM
ECLIPSE (W/ KEYLESS ENTRY), ECLIPSE SPYDER
ECLIPSE (W/O KEYLESS ENTRY)
ECLIPSE SPYDER (TURBO), ECLIPSE
FOR CD AUTO CHANGER
GRN/WHT WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN
HOT IN RUN, START
IF NOT EQUIPPED
INTERIOR LIGHT SYSTEM, DOOR LOCK SYSTEM
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT DOOR SPEAKER
LEFT FRONT SPEAKER (IF EQUIPPED)
LEFT REAR SPEAKER
MOTOR ANTENNA ASSEMBLY (IF EQUIPPED) (LEFT SIDE OF LUGGAGE COMPARTMENT)
MULTI- PURPOSE FUSE 1
MULTI- PURPOSE FUSE 8
NOT USED
RADIO WITH CD/ TAPE PLAYER
RED WIRE
RED/BLK WIRE
RIGHT DOOR SPEAKER
RIGHT FRONT SPEAKER (IF EQUIPPED)
RIGHT REAR SPEAKER
W/ MOTOR ANTENNA
W/ POLE ANTENNA
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDOW ANTENNA (IF EQUIPPED)
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Radio circuits, without amplifier -> IF NOT EQUIPPED
