Mitsubishi Eclipse II (1994-1999) cruise control system, engine control system wiring diagram
This page shows the only wiring diagram for the component.cruise control system, engine control system, which is found in the car Mitsubishi Eclipse II (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
cruise control system, engine control system wiring diagram (1 of 1)
1 3 (1996-97) (1998-99)
2 3 (1996-97) (1998-99)
3 4 (1996-97) (1998-99)
A/T ONLY
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH (BEHIND DASH, ON CLUTCH PEDAL SUPPORT)
CRUISE CONTROL SYSTEM, ENGINE CONTROL SYSTEM
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENG COMPT)
FUSIBLE LINK 4
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
IGNITION SWITCH
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
J/C 4 (LEFT FRONT OF ENG COMPT)
M/T ONLY (LEFT REAR OF ENG, NEAR STARTER MOTOR)
NCA WIRE
OFF
RED/BLK WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (BEHIND CENTER OF DASH)
TRANSAXLE RANGE SWITCH (LEFT SIDE OF TRANS- AXLE)
W/ A/T
W/ M/T
YEL WIRE
Go to component -> 2.0l, starting circuit, without anti-theft -> CRUISE CONTROL SYSTEM, ENGINE CONTROL SYSTEM
