Mitsubishi Eclipse II (1994-1999) 66 65 75 pnk Wiring diagram
This page shows the only wiring diagram for the component.66 65 75 pnk, which is found in the car Mitsubishi Eclipse II (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 66 65 75 pnk (1 of 1)
66 65 75 PNK WIRE
A/T
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/RED WIRE
COMBINATION METER
DATA LINK CONNECTORS (BELOW LEFT SIDE OF DASH)
DEDICATED FUSE 11
EATX-ECM (BEHIND CENTER OF DASH)
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
HOT AT ALL TIMES
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
J/C 4 (BELOW ENGINE COMPARTMENT RELAY BOX)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
M/T
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPARTMENT)
RECEIVER (BEHIND LEFT REAR QUARTER PANEL TRIM)
RED/BLK WIRE
SPEEDOMETER
SRS-ECU (BELOW FRONT OF CONSOLE)
VEHICLE SPEED SENSOR (ON RIGHT SIDE OF TRANSAXLE)
WHT/BLU WIRE
YEL WIRE
YEL/GRN (OR YEL/BLK) WIRE
YEL/WHT WIRE
Go to component -> 2.0l, computer data lines -> 66 65 75 PNK WIRE
