Telematics circuit for Mitsubishi Eclipse Cross I facelift (2020-2024)

BATTERY BLK WIRE BLU WIRE BRN WIRE C-108 C-111 C-114 C-243 C-251 C-252-1 C-402 C-403 CAN (+) COMPUTER DATA LINES SYSTEM CSIG DASH GROUNDING J/C (C-202) ETACS-ECU FUSE 15 FUSE 18 GND C-252 GNSS ANTENNA GRN WIRE GRY WIRE H-18 H-19 HOT AT ALL TIMES J/C 2 (C-106) J/C 3 (C-105) J/C 4 (C-104) J/C 8 (C-103) J/C 9 (C-135) JDSP LT BLU WIRE LT GRN WIRE MGND MI+ MIC - MICROPHONE UNIT MISH MO- MULTI VISION DISPLAY MUTE NCA WIRE PNK MI+ WIRE PNK SPO- WIRE PNK WIRE RED WIRE RELAY ENERGIZED SNSE SNSI SNSO SPO- SRS ECU TBAC C-141 TEL ANTENNA TELEMATICS CONTROL UNIT VIO WIRE WHT WIRE YEL WIRE

AUDIO AMPLIFIER BLK WIRE BLU WIRE C-128 C-243 C-251 DFR- DSI- DSO+ ECALL RELAY BOX ASSEMBLY ECALL SPEAKER ECALL, BCALL SWITCH ESI+ ESO GRN WIRE IND (GREEN) IND (RED) WIRE INFORMATION SWITCH INFORMATION SWITCH ILL (AMBER) INFORMATION SWITCH IND J/C 11 (C-126) J/C 12 (C-127) J/C 9 (C-135) LT BLU WIRE LT GRN WIRE PNK WIRE PPL/BLU WIRE PPL/RED WIRE RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR SPEAKER SOS SWITCH SOS SWITCH ILL (RED) WIRE SOS SWITCH IND VIO WIRE W/ AUDIO AMPLIFIER W/O AUDIO AMPLIFIER WHT WIRE YEL WIRE
