Navigation circuit, w/ amplifier for Mitsubishi Eclipse Cross I facelift (2020-2024)

ANT ANTENNA BLK WIRE BLU WIRE BRN WIRE C-124 C-138 C-149 C-208 C-209 C-241 C-403 C-418 CAN (+) COMPUTER DATA LINES SYSTEM DASH GROUNDING J/C (C-202) ENGINE COMPARTMENT RELAY BOX ETACS-ECU FUSE 17 FUSE 18 FUSE 22 GND C-114 GPS ANTENNA GRN WIRE GRY WIRE H-01 H-02 H-03 H-04 H-05 H-15 H-16 H-17 H-21 HOT AT ALL TIMES HOT W/ J/C 12 (C-127) (RIGHT END OF DASH) J/C 5 (C-209, C-208) J/C 7 (C-206) (CENTER OF DASH) LEFT FRONT DOOR SPEAKER LT BLU WIRE LT GRN WIRE MULTI VISION DISPLAY NCA WIRE PNK CAN- WIRE PNK WIRE PPL/BLU WIRE PPL/RED WIRE RED WIRE RELAY 2 ENERGIZED SWG USB ADAPTER USB CABLE VIO WIRE W/ AUDIO AMPLIFIER W/O AUDIO AMPLIFIER WHT WIRE

BLK WIRE BLU WIRE BRN WIRE C-108 C-116 C-128 C-249 CACC CGND CMP COMBINATION METER COMPUTER DATA LINES SYSTEM DSI- ECALL RELAY BOX ASSEMBLY (W/ TCU) (UNDER FRONT OF CENTER CONSOLE) GRN WIRE GRY WIRE J/C 11 (C-126) (RIGHT END OF DASH) LEFT TWEETER LT BLU WIRE LT GRN WIRE MGND MIC - MULTI VISION DISPLAY NAVIGATION SYSTEM PNK (OR BRN) WIRE PNK WIRE PPL/BLU WIRE PPL/RED WIRE REAR VIEW CAMERA CIRCUIT RED WIRE REV RIGHT FRONT DOOR SPEAKER RIGHT TWEETER SNSE VIO WIRE W/ AUDIO AMPLIFIER W/ AUDIO AMPLIFIER, TCU W/ TCU W/O AUDIO AMPLIFIER W/O AUDIO AMPLIFIER, W/ TCU W/O TCU WHT WIRE YEL WIRE

AUDIO AMPLIFIER (UNDER FRONT PASSENGER'S SEAT) BLK WIRE BLU WIRE BRN WIRE C-132 C-148 C-208 C-209 C-233 D-117 D-127 D-54 D-55 DFL- DFR- GRN WIRE GRY WIRE IEH IEL J/C 3 (C-105) J/C 5 (C-209, C-208) LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE P-ON PNK WIRE PPL/BLU WIRE PPL/VIO WIRE RED WIRE RIGHT REAR DOOR SPEAKER RR+I TFL TFR- VIO WIRE W/ AUDIO AMPLIFIER W/O AUDIO AMPLIFIER WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE C-223 C-243 C-303 C-312 CAMERA SWITCH CH DOWN CH UP CLOCKSPRING D-S- D-S- C-111 GRN WIRE GRY WIRE ILL J/C 2 (C-106) J/C 5 (C-209) J/C 7 (C-206) (CENTER OF DASH) LT GRN WIRE MODE MULTI VISION DISPLAY MUTE NAVIGATION SYSTEM (TELEMATICS CIRCUIT) NCA WIRE NOT USED NOT USED OFF HOOK ON HOOK PNK WIRE RED WIRE SPEECH STEERING WHEEL REMOTE CONTROL SWITCH TIL- TIR+ VIO WIRE VOL DOWN VOL UP WHT WIRE
