Mitsubishi Eclipse Cross I facelift (2020-2024) Lane departure warning circuit

ASC-ECU BLK WIRE BLU WIRE BRN WIRE C-150 C-402 C-414 CAN DRIVE CIRCUIT CNMH CNML COMBINATION METER COMBINER COMPUTER DATA LINES SYSTEM DASH GROUNDING J/C (C-202) ETACS-ECU FCM ON/OFF SWITCH FCM/LDW/ AHB-ECU FCSW FORWARD COLLISION MITIGATION SYSTEM OFF IND LIGHT FORWARD COLLISION MITIGATION SYSTEM WARNING, LANE DEPARTURE WARNING DISPLAY FUSE 15 GRN WIRE HUD ILL INTERFACE CIRCUIT J/C 4 (C-104) LANE DEPARTURE WARNING DISPLAY LCD LDW SWITCH LDWS LT BLU WIRE LT GRN WIRE PNK CANH WIRE PNK WIRE RED WIRE RELAY ENERGIZED VIO WIRE WHT WIRE YEL WIRE
