Mitsubishi Eclipse Cross I facelift (2020-2024) right liftgate power unit Wiring diagram
This page shows the only wiring diagram for the component.right liftgate power unit, which is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right liftgate power unit (1 of 1)
AJAR SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
C-147
C-148
C-150
C-403
C-412
C-414
CAN DRIVE CIRCUIT
CLOSE SWITCH
COMPUTER DATA LINES SYSTEM
D-108
D-141
DASH GROUNDING J/C (C-202)
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU
FUSE 19
FUSIBLE LINK 5
GRN WIRE
GRY WIRE
HALF LATCH SWITCH
HOT AT ALL TIMES
ILL
INTERFACE CIRCUIT
J/C 30 (D-56)
J/C 4 (C-104)
J/C 7 (C-206)
LEFT LIFTGATE POWER UNIT (IN LEFT "C" PILLAR)
LIFTGATE LATCH (BOTTOM CENTER OF LIFTGATE)
LT BLU WIRE
LT GRN WIRE
MENU SWITCH
MULTI- INFORMATION DISPLAY SWITCH
NCA WIRE
OPEN SWITCH
PGL+ D-59
PGL-
PGR
PLCL
PLOP
POWER LATCH MOTOR
POWER LIFTGATE CONTROL UNIT
PSGR
RED WIRE
RIGHT LIFTGATE POWER UNIT
SCREEN SWITCHING DOWN SWITCH
SCREEN SWITCHING UP SWITCH
TRID
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power liftgate circuit (1 of 2) -> RIGHT LIFTGATE POWER UNIT
