Mitsubishi Eclipse Cross I facelift (2020-2024) position/ side marker light Wiring diagrams
This page contains all the electrical diagrams for the component. position/ side marker light, in which he is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram position/ side marker light (1 of 2)
A-114
ASC-ECU
ASTP
BLK WIRE
BLU WIRE
BRAKE MONITORING SWITCH
BRK
BRN WIRE
C-150
C-29
C-410 C-417
C-419
CANL B-10
COMPUTER DATA LINES SYSTEM
D-108
DASH GROUNDING J/C (C-202)
DRIVER'S SIDE FRONT DOOR SWITCH
ENGINE CONTROL MODULE
ETACS-ECU
FUSE 14
GRN WIRE
GRY WIRE
HAZARD WARNING LIGHT SWITCH
HOT AT ALL TIMES
ILL
J/C 15 (C-136)
J/C 4 (C-104)
KOS, OSS-ECU
LEFT FRONT COMBINATION LIGHT
LEFT LICENSE PLATE LIGHT
LEFT TAILLIGHT
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF
PNK WIRE
POSITION/ SIDE MARKER LIGHT
RED WIRE
RIGHT FRONT COMBINATION LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT TAILLIGHT
SPARE CONNECTOR (SWITCH BOX)
SPARE CONNECTOR (TRAILER HARNESS)
STOP LIGHT CONTROL CIRCUIT
STOP LIGHT SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> POSITION/ SIDE MARKER LIGHT
Wiring diagram position/ side marker light (2 of 2)
3 4 W/O DOOR TRIM ILLUMINATION
A-23
B-10
B-11
BATTERY
BLIND SPOT WARNING LIGHT
BLK WIRE
BLK/GRY WIRE
C-240
DATA LINK CONNECTOR
DRIVER SIDE FRONT DOOR LOCK ACTUATOR
DRIVER SIDE FRONT DOOR OUTSIDE HANDLE LOCK/ UNLOCK SWITCH
DRIVER'S SIDE FRONT DOOR INSIDE HANDLE ILLUMINATION
ENGINE CONTROL MODULE
F-09
F-15
F-16
F-17
F-26
F-30
GRY WIRE
HEATER
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LEFT DOOR MIRROR ASSEMBLY
LEFT FRONT COMBINATION LIGHT
LEFT FRONT COMPARTMENT LIGHT
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT SIDE TURN SIGNAL LIGHT
LINEAR AIR-FUEL RATIO SENSOR SHIELD
NCA WIRE
POSITION/ SIDE MARKER LIGHT
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REMOTE CONTROLLED MIRROR SWITCH
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT COMPARTMENT LIGHT
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
TO DASH GROUNDING J/C (C-202) (DIAGRAM 1 OF 4)
W/ ONE TOUCH OPENING/CLOSING FOR ALL WINDOWS
W/ ONE TOUCH OPENING/CLOSING FOR DRIVER'S WINDOWS
W/ SIDE VIEW CAMERA
W/O SIDE VIEW CAMERA
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 4) -> POSITION/ SIDE MARKER LIGHT
