Mitsubishi Eclipse Cross I facelift (2020-2024) passenger's side front door assist grip illumination Wiring diagram
This page shows the only wiring diagram for the component.passenger's side front door assist grip illumination, which is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side front door assist grip illumination (1 of 1)
BLK WIRE
BLU WIRE
C-129
C-240
C-402
C-403
C-414
C-418
DRIVER'S SIDE FRONT DOOR ASSIST GRIP ILLUMINATION
DRIVER'S SIDE FRONT DOOR BOTTLE HOLDER ILLUMINATION
DRIVER'S SIDE FRONT DOOR INSIDE HANDLE ILLUMINATION
ETACS-ECU
F-23
F-26
F-28
F-30
FUSE 15
FUSE 18
FUSE 19
GRN WIRE
HOT AT ALL TIMES
HOT W/
INTERFACE CIRCUIT
J/C 3 (C-105)
LIN DRIVE CIRCUIT
LT BLU WIRE
PASSENGER'S SIDE FRONT DOOR ASSIST GRIP ILLUMINATION
PASSENGER'S SIDE FRONT DOOR BOTTLE HOLDER ILLUMINATION
PASSENGER'S SIDE FRONT DOOR INSIDE HANDLE ILLUMINATION
PNK WIRE
PPL/GRN WIRE
PPL/YEL WIRE
RED WIRE
VIO WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> PASSENGER'S SIDE FRONT DOOR ASSIST GRIP ILLUMINATION
