Mitsubishi Eclipse Cross I facelift (2020-2024) engine compartment relay box fan control relay Wiring diagram
This page shows the only wiring diagram for the component.engine compartment relay box fan control relay, which is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine compartment relay box fan control relay (1 of 1)
A-109
ACC/FCM- ECM
ACCESSORY SOCKET (REAR FLOOR CONSOLE)
ASC-ECU
AWC-ECU
B-10
BLK WIRE
BRAKE FLUID LEVEL SWITCH
C-21
C-227
C-23
C-31
CONDENSER FAN MOTOR
CVT
D-127
E-01
E-13
E-14
ELECTRIC PARKING BRAKE ECU
ENGINE COMPARTMENT RELAY BOX
ENGINE COMPARTMENT RELAY BOX FAN CONTROL RELAY
ENGINE CONTROL MODULE
EPS-ECU
FCM/LDW/ AHB-ECU
FRONT DOME LIGHT
FRONT SHADE MOTOR ASSEMBLY
FRONT SHADE SWITCH
HEATED SEAT RELAY
HOOD LATCH SWITCH
INSIDE REAR VIEW MIRROR ASSEMBLY
LEFT REAR HEATED SEAT SWITCH
LEFT VANITY MIRROR LIGHT
LIGHTING CONTROL SENSOR
NCA WIRE
PRIMARY PULLEY SPEED SENSOR
REAR DOME LIGHT
REAR SHADE MOTOR ASSEMBLY
REAR SHADE SWITCH
RIGHT REAR COMBINATION LIGHT
RIGHT REAR HEATED SEAT SWITCH
RIGHT REAR POWER WINDOW SUB SWITCH
RIGHT VANITY MIRROR LIGHT
SECONDARY PULLEY SPEED SENSOR
STOP LIGHT
STOP LIGHT SWITCH
SUNROOF MOTOR ASSEMBLY,
SUNROOF SWITCH
TAILLIGHT/ SIDE MARKER LIGHT
TRANSAXLE CONTROL MODULE
TURBINE SPEED SENSOR
TURN SIGNAL
USB ADAPTER (FOR CHARGING)
W/O PANORAMA
WINDSHIELD WASHER TANK FLUID LEVEL SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> ENGINE COMPARTMENT RELAY BOX FAN CONTROL RELAY
