Mitsubishi Eclipse Cross I facelift (2020-2024) electric power steering system warning Wiring diagram
This page shows the only wiring diagram for the component.electric power steering system warning, which is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electric power steering system warning (1 of 1)
+B C-21
BLK WIRE
BLU WIRE
BRN WIRE
C-149
C-21-1
C-22
C-23
C-24
C-402
C-414
CAN DRIVE CIRCUIT
CAN L
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DASH GROUNDING J/C (C-202)
ELECTRIC POWER STEERING SYSTEM WARNING
ELECTRIC POWER STEERING SYSTEM WARNING LIGHT IND
EPS-ECU (ON STEERING COLUMN)
ETACS-ECU
FUSE 15
FUSIBLE LINK 38
FUSIBLE LINK BOX
GRN WIRE
HOT AT ALL TIMES
HOT W/
INTERFACE CIRCUIT
J/C 1 (C-01)
J/C 8 (C-103)
LCD
LT BLU WIRE
MOTOR
NCA WIRE
PNK CAN-H WIRE
RESOLVER
TORQUE SENSOR
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> ELECTRIC POWER STEERING SYSTEM WARNING
