Mitsubishi Eclipse Cross I facelift (2020-2024) bsw setting rear cross traffic alert message Wiring diagrams
This page contains all the electrical diagrams for the component. bsw setting rear cross traffic alert message, in which he is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bsw setting rear cross traffic alert message (1 of 2)
BLIND SPORT WARNING INDICATOR LIGHT
BLIND SPOT WARNING LIGHT
BLK WIRE
BLU WIRE
BRN WIRE
BSW SETTING REAR CROSS TRAFFIC ALERT MESSAGE
BSW-ECU (MASTER)
BSW-ECU (SLAVE)
C-128
C-147
C-241
C-310
C-315
C-402
C-412
CAN L
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-16
DASH GROUNDING J/C (C-202)
ETACS-ECU
FUSE 15
GRN WIRE
GRY WIRE
J/C 4 (C-104)
LCD
LEFT DOOR MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL/BRN WIRE
RELAY ENERGIZED
RIGHT DOOR MIRROR ASSEMBLY
STEERING WHEEL SENSOR
VIO WIRE
W/ SIDE VIEW CAMERA
W/O SIDE VIEW CAMERA
YEL WIRE
Go to component -> Blind spot monitoring circuit -> BSW SETTING REAR CROSS TRAFFIC ALERT MESSAGE
