Mitsubishi Eclipse Cross I facelift (2020-2024) blind sport warning indicator light Wiring diagram
This page shows the only wiring diagram for the component.blind sport warning indicator light, which is found in the car Mitsubishi Eclipse Cross I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blind sport warning indicator light (1 of 1)
BLIND SPORT WARNING INDICATOR LIGHT
BLIND SPOT WARNING LIGHT
BLK WIRE
BLU WIRE
BRN WIRE
BSW SETTING REAR CROSS TRAFFIC ALERT MESSAGE
BSW-ECU (MASTER)
BSW-ECU (SLAVE)
C-128
C-147
C-241
C-310
C-315
C-402
C-412
CAN L
COLUMN SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D-16
DASH GROUNDING J/C (C-202)
ETACS-ECU
FUSE 15
GRN WIRE
GRY WIRE
J/C 4 (C-104)
LCD
LEFT DOOR MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL/BRN WIRE
RELAY ENERGIZED
RIGHT DOOR MIRROR ASSEMBLY
STEERING WHEEL SENSOR
VIO WIRE
W/ SIDE VIEW CAMERA
W/O SIDE VIEW CAMERA
YEL WIRE
Go to component -> Blind spot monitoring circuit -> BLIND SPORT WARNING INDICATOR LIGHT
