Courtesy lamps circuit for Mitsubishi Eclipse Cross I (2017-2022)

BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE C-241 C-401 C-405 C-408 C-414 CAN DRIVE CARGO ROOM LIGHT CIRCUIT COMPUTER DATA LINES SYSTEM CONTROL CIRCUIT D-108 DAS DDR DDUK DLH DRH DRIVER'S SIDE FRONT DOOR LOCK ACTUATOR DRIVER'S SIDE FRONT DOOR SWITCH ETACS-ECU (LEFT END OF DASH) FUSE 19 FUSIBLE LINK 40 FUSIBLE LINK BOX GLP- C-416 GRN WIRE HOT AT ALL TIMES INTERFACE INTERIOR LIGHT) LATCH SWITCH LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LIFTGATE LATCH LP+2 LT GRN WIRE OFF OFF OFF PASSENGER'S SIDE FRONT DOOR SWITCH PNK WIRE PPL/VIO WIRE RED WIRE RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) RLP TAIL LIGHT CONTROL CIRCUIT TRID C-412 VIO WIRE WHT WIRE

BLK WIRE BLU WIRE BRN WIRE C-243 DASH GROUNDING J/C (C-202) DOOR E-14 FRONT DOME LIGHT GRN WIRE IGNITION KEY CYLINDER ILLUMINATION LIGHT J/C 4 (C-104) LEFT VANITY MIRROR LIGHT NCA WIRE OFF PNK WIRE REAR DOME LIGHT RIGHT VANITY MIRROR LIGHT
